| 定货序号 Order No | 规格 Dimension (mm) | 精度等级 Grade | |||||
| 工作面直线度公差 Beeline tolerance of working surface (μm） | 上下工作面平行度公差 Parallelism tolerance between the upper and lower measuring surfaces (μm） | 侧面与工作面垂直度 Perpendicularity between side & measuring surface (μm） | |||||
| 精度0 | 精度00 | 精度0 | 精度00 | 精度0 | 精度00 | ||
| CVA238001 | 400*60*25 | 1.6 | 1.6 | 3.9 | 2.4 | 13 | 8 |
| CVA238002 | 630*100*35 | 3.5 | 2.1 | 5.3 | 3.2 | 18 | 10.5 |
| CVA238003 | 1000*160*50 | 5 | 3 | 7.5 | 4.5 | 25 | 15 |
| CVA238004 | 1600*250*80 | 7.4 | 4.4 | 11.1 | 6.6 | 37 | 22 |
| CVA238005 | 2000*300*100 | 9 | 5.4 | 13.5 | 8.1 | 45 | 27 |
