| 定货序号 Order No | 规格 Dimension (mm) | 精度等级 Grade | |||||
| 平行度 Parallelism of working surface | 平面度 Flatness of working surface | 垂直度 Perpendicularity of working surface | |||||
| 0 | 00 | 0 | 00 | 0 | 00 | ||
| CVA239-1 | 50x50x50 | 0.002 | 0.001 | 0.002 | 0.001 | 0.001 | 0.0005 |
| CVA239-2 | 100x100x100 | 0.002 | 0.001 | 0.002 | 0.001 | 0.002 | 0.001 |
| CVA239-3 | 150x150x150 | 0.003 | 0.0015 | 0.002 | 0.001 | 0.003 | 0.0015 |
| CVA239-4 | 200x200x200 | 0.004 | 0.002 | 0.003 | 0.0015 | 0.004 | 0.002 |
| CVA239-5 | 300x300x300 | 0.006 | 0.003 | 0.003 | 0.0015 | 0.006 | 0.003 |
| CVA239-6 | 400x400x400 | 0.008 | 0.004 | 0.004 | 0.002 | 0.008 | 0.004 |
| CVA239-7 | 500x500x500 | 0.010 | 0.005 | 0.005 | 0.0025 | 0.010 | 0.005 |
| CVA239-8 | 600x600x600 | 0.012 | 0.006 | 0.006 | 0.003 | 0.012 | 0.006 |
| CVA239-9 | 700x700x700 | 0.014 | 0.007 | 0.007 | 0.0035 | 0.014 | 0.007 |
| CVA239-10 | 800x800x800 | 0.016 | 0.008 | 0.008 | 0.004 | 0.016 | 0.008 |
