| 定货序号 Order No | 规格 Dimension (mm) | 精度等级 Grade | |||||||
| 工作面的平直度 Flatness and beeline of the measuring (μm） | 两工作面间的平行度 Parallelism between two measuring surfaces (μm） | 工作面与侧面的垂直度Perpendicularity between measuring surface and side surfaces (μm） | 每对平行规的等高度Height difference of the paralells within a matched pair (μm） | ||||||
| 精度0 | 精度00 | 精度0 | 精度00 | 精度0 | 精度00 | 精度0 | 精度00 | ||
| CVA237001 | 100*63*16 | 3 | 1.5 | 3 | 1.5 | 10 | 5 | 3 | 1.5 |
| CVA237002 | 160*40*25 | 3 | 1.5 | 3 | 1.5 | 10 | 5 | 3 | 1.5 |
| CVA237003 | 250*40*25 | 4 | 2 | 4 | 2 | 20 | 10 | 4 | 2 |
| CVA237004 | 400*63*40 | 8 | 4 | 8 | 4 | 30 | 15 | 8 | 4 |
| CVA237005 | 630*100*63 | 12 | 6 | 12 | 6 | 40 | 20 | 12 | 6 |
