| 定货序号 Order No | 规格 Dimension (mm) | 重量 Weight (kg) | 对角线(d) Length of Diagonal (mm) | 精度 000 (μm) | 精度 00 (μm) | 精度 0 (μm) | 精度 1 (μm) |
| CVA234001 | 300x200x50 | 9 | 360 | 1.5 | 3 | 5.5 | 11 |
| CVA234002 | 300x300x70 | 19 | 424 | 1.5 | 3 | 5.5 | 11 |
| CVA234003 | 400x250x70 | 21 | 472 | 1.5 | 3 | 6 | 12 |
| CVA234004 | 400x400x100 | 48 | 568 | 2 | 3.5 | 6.5 | 13 |
| CVA234005 | 630x400x100 | 76 | 764 | 2 | 3.5 | 7 | 14 |
| CVA234006 | 630x630x130 | 155 | 891 | 2 | 4 | 8 | 16 |
| CVA234007 | 800x500x130 | 156 | 943 | 2 | 4 | 8 | 16 |
| CVA234008 | 1000x630x150 | 284 | 1182 | 2.5 | 4.5 | 9 | 18 |
| CVA234009 | 1000x750x150 | 338 | 1250 | 2.5 | 4.5 | 9 | 18 |
| CVA234010 | 1000x1000x150 | 450 | 1411 | 2.5 | 5 | 10 | 20 |
| CVA234011 | 1200x800x150 | 432 | 1442 | 2.5 | 5 | 10 | 20 |
| CVA234012 | 1600x1000x200 | 960 | 1887 | 3 | 6 | 12 | 24 |
| CVA234013 | 2000x1000x250 | 1500 | 2136 | 3.5 | 6.5 | 13 | 26 |
| CVA234014 | 2000x1600x300 | 2880 | 2561 | 3.5 | 7 | 14 | 28 |
| CVA234015 | 2500x1600x300 | 3600 | 2968 | 4 | 8 | 16 | 32 |
| CVA234016 | 3000x2000x400 | 9000 | 3605 | 4.5 | 9 | 18 | 36 |
| CVA234017 | 4000x2500x500 | 15350 | 4717 | 6 | 11.5 | 23 | 46 |
